JIS S45C, S50C, S55C Forged Steel Blocks
JIS S45C, S50C, S55C Forged Steel Blocks
JIS S45C, S50C, S55C Forged Steel Blocks
JIS S45C, S50C, S55C Forged Steel Blocks
JIS S45C, S50C, S55C Forged Steel Blocks

JIS S45C, S50C, S55C Forged Steel Blocks

Model NO.:
Carbon steel S45C Block
Delivery:
FOB

JIS S45C,S50C,S55C Forged Steel Blocks


Dimensions

Thickness (mm) Width (mm) Length (mm)
300-1200300-16002000-5800

Delivery Condition

EAF+LF+VD, Forged, Untreated or Normalized, UT 100% Passed

Chemical Composition(%)

Steel Grade CSiMnPSCrNi
S45C0.42-0.480.15-0.350.60-0.90≤ 0.030 ≤ 0.035 ≤ 0.20 ≤ 0.20
S50C0.47-0.530.15-0.350.60-0.90≤ 0.030 ≤ 0.035 ≤ 0.20 ≤ 0.20
S55C0.52-0.580.15-0.350.60-0.90≤ 0.030 ≤ 0.035 ≤ 0.20 ≤ 0.20

Characteristics
It is a medium carbon steel is used when greater strength and hardness is desired than in the"as rolled"condition. Extreme size accuracy, straightness and concentricity combine to minimize wear in high speed applications.

Applications
It is used for making large sized of plastic mould, or mold base. It is also a kind of Quenched and subsequently tempered steel for screws, forgings, wheel tyres, shafts, sickles, axes, knives, wood working drills, hammers, etc.
