Hot Rolled Steel Plate 1045 / C45 / S45C
Hot Rolled Steel Plate 1045 / C45 / S45C
Hot Rolled Steel Plate 1045 / C45 / S45C
Hot Rolled Steel Plate 1045 / C45 / S45C
Hot Rolled Steel Plate 1045 / C45 / S45C
Hot Rolled Steel Plate 1045 / C45 / S45C
Hot Rolled Steel Plate 1045 / C45 / S45C

Hot Rolled Steel Plate 1045 / C45 / S45C

Model NO.:
Carbon steel C45 Plate
Delivery:
FOB
Quantity:

Hot Rolled Steel Plate 1045 | C45 | S45C


Dimensions

Thickness (mm) Width (mm) Length (mm)
10-5002000-23003000-5800
47 sets of Vertical Band Saw Strong cutting capacity!!! Monthly 250tons per set We guarantee a prompt delivery time We cut and machine the steel plate as your required sizes P20+Ni is recommended for the Blocks thickness over 450mm

Delivery Condition

EAF+LF+VD, Hot Rolled or Forged, Black surface or Machined surface (Peeled, Turned, Grinded), Untreated or Normalized, UT 100% Passed

Equivalence

AISI / SAE DIN / W.Nr JISGB
1045CK45 C45E 1.1191 S45C45#

Chemical Composition(%)

Steel Grade CSiMnPSCrNi
CK45 C45E 1.1191 0.42-0.50≤ 0.40 0.50-0.80≤ 0.035 ≤ 0.035 ≤ 0.20 ≤ 0.10
10450.43-0.50----0.60-0.90≤ 0.040 ≤ 0.050 ≤ 0.05 ----
S45C0.42-0.480.15-0.350.60-0.90≤ 0.030 ≤ 0.035 ≤ 0.20 ≤ 0.20

Characteristics

AISI 1045 is a medium carbon steel is used when greater strength and hardness is desired than in the
"as rolled"condition. Extreme size accuracy, straightness and concentricity combine to minimize wear
in high speed applications.

Applications
Quenched and subsequently tempered steel for screws, forgings, wheel tyres, shafts, sickles, axes, knives, wood working drills, hammers, etc
