1.2363
DIN 1.2363 / AISI A2 Tool Steel
We offer a wide range of DIN 1.2363 / AISI A2 Tool Steel products in a wide variety of dimensions and executions, acc.to the common international specifications or customerized.
tool steel 1.2363
FOB
Quantity:

DIN 1.2363 / AISI A2 Cold Work Tool Steel

A2,1.2363


DIN 1.2363 / AISI A2 Cold Work Tool Steel is used for making cutting tools (dies and punches), blanking and punching tools, thread rolling dies, shear blades, trim dies, forming dies, gauges, stamping dies etc..

Dimensions
Round: dia.10-400 mm
Flat: 6-120 x 40-810 mm
Block: 80-350 x 100-700 mm

Delivery Condition
EAF+(ESR) or EAF+LF+VD+(ESR), Hot rolled or Forged, Annealed, Black surface or Machined surface, UT SEP1921 Class3 D/d

Equivalence

AISI / SAE
DIN / W.Nr JISGB
A21.2363SKD12Cr5Mo1V

Chemical Composition(%)

Steel Grade CSiMnPSCrMoV
1.23630.95-1.050.10-0.400.40-0.80≤ 0.030 ≤ 0.030 4.80-5.500.90-1.200.15-0.35
A20.95-1.050.10-0.500.40-1.00≤ 0.030 ≤ 0.030 4.75-5.500.90-1.400.15-0.50

Characteristics

1. A kind of air hardening tool steel.

2. Good toughness with medium wear resistance and relatively easy to machine.

Heat Treatment
Annealing
800 to 850°C
Slow controlled cooling in furnace at a rate of 10 to 20°C/hr down to approx. 600°C, further cooling in air.
Hardness after annealing: max. 235 HB.


Hardening
950 to 980°C
Oil, salt bath (200 to 250°C or 500 to 550°C), air blast, still air. Tools of intricate shape or with sharp edges should preferably be hardened in air or salt bath. Holding time after temperature equalization:15 to 30 minutes. Obtainable hardness: 63 - 65 HRC


Stress relieving
Approx. 650°C
Slow cooling in furnace. Intended to relieve stresses set up by extensive machining, or in complex shapes. After through heating, hold in neutral atmosphere for 1 - 2 hours.

Tempering
Slow heating to tempering temperature immediately after hardening/time in furnace 1 hour for each 20 mm of workpiece thickness, but at least 2 hours/cooling in air. For certain cases we recommend to reduce tempering temperature and increase holding time.
