1045 / C45 / S45C Carbon Steel Bar
1045 / C45 / S45C Carbon Steel Bar
1045 / C45 / S45C Carbon Steel Bar
1045 / C45 / S45C Carbon Steel Bar
1045 / C45 / S45C Carbon Steel Bar

1045 / C45 / S45C Carbon Steel Bar

Model NO.:
Carbon steel 1045 Bar
Delivery:
FOB

1045 | C45 | S45C Carbon Steel Round Bar


Dimensions
Hot Rolled Round: dia.10-300 mm.
Forged Round: dia.150-1500 mm.

Delivery Condition
EAF+LF+VD, Hot Rolled or Forged, Black surface or Machined surface (Peeled, Turned, Grinded), Untreated or Normalized, UT 100% Passed

Equivalence

AISI / SAE DIN / W.Nr JISGB
1045CK45 C45E 1.1191 S45C45#

Chemical Composition(%)

Steel Grade CSiMnPSCrNi
CK45 C45E 1.1191 0.42-0.50≤ 0.40 0.50-0.80≤ 0.035 ≤ 0.035 ≤ 0.20 ≤ 0.10
10450.43-0.50----0.60-0.90≤ 0.040 ≤ 0.050 ≤ 0.05 ----
S45C0.42-0.480.15-0.350.60-0.90≤ 0.030 ≤ 0.035 ≤ 0.20 ≤ 0.20

Characteristics
AISI 1045 is a medium carbon steel is used when greater strength and hardness is desired than in the
"as rolled"condition. Extreme size accuracy, straightness and concentricity combine to minimize wear
in high speed applications.

Applications
Quenched and subsequently tempered steel for screws, forgings, wheel tyres, shafts, sickles, axes, knives, wood working drills, hammers, etc.
